KT15 hydraulic intergrated bore pile rotary drilling rig -
KT15 hydraulic intergrated bore pile rotary drilling rig
Main features and Specification of KT15 Integrated DTH drilling rig,pneumatic 150m water well drilling rig, powerful for granite, marble, etc.
KT15 hydraulic intergrated bore pile rotary drilling rig machine price
1. Main features and Specification of KT15 Integrated DTH drilling rig,pneumatic 150m water well drilling rig, powerful for granite, marble, etc.
Rock Rigidity | f=6-20 |
Drilling diameter(mm) | 135-190 |
Drilling Depth (m) | 35 |
Traveling Speed (Km/h) | 3.0 |
Climb Capacity° | 25° |
Ground Clearance (mm) | 430 |
Power(Kw) | 298 |
Engine Model | Commins QSZ13-C400 |
Air Consumption (m3/min) | 22 |
Screw compressor work pressure(Mpa) | 25 |
Working Pressure(bar) | 20 |
Dimension(mm) | 11500 ×2716×3540 |
Weight( Kg ) | 23000 |
Rotation Speed(r/min) | 0-118 |
Rotatio Torque(N*m) | 4100 |
Max. Feed Force(N) | 65000 |
Guide Tilt | 125° |
Guide Swing | right97°left33° |
Boon Swing | right42°left15° |
Crawler Balance Angle | up10°down10° |
Feed stroke( mm) | 5000 |
Compensation stroke(mm) | 1800 |
Hammer | HD55A |
Rod(mm) | φ89×5000/φ102×5000 |
| Catching dust method | dry-type or wet-type |
| Extension rod method | Automatic discharge rod |
| Automatic protection lock method | The electro-hydraulic control |
| Drill pipe lubricating method | Automatic oil lubrication |
| Drill pipe thread protection | Equipped with floating joint protection drill pipe thread |
| Real-time display Angle of drilling and drilling depth |
2.Application of KT15 Integrated DTH drilling rig,pneumatic 150m water well drilling rig, powerful for granite, marble, etc.
The KT15 type DTH crawler drill is mainly used in large-scale open-pit mines and quarres.etc.The main hydraulic components and diesel engines are inportanted products.It comes with a 22/20 high pressure screw head and high drilling efficiency.The htdraulic dry dust collector cab collect the dust and reduce pollution,while the use of automatic unloading rods reduces labor intensity.The air conditioned cab provides a comfortable working environment and the automatic control anti-jamming valve reduces the probability of getting stuck.
3. Working of KT15 Integrated DTH drilling rig,pneumatic 150m water well drilling rig, powerful for granite, marble, etc.
4.We also provide other Mining operations.
5.Spare parts supermarket
